S18

The Quint Audio S18 is an 18″ ND subwoofer with a linear bass reflex tuning to be used as (sub)bass extension of Quint Audio loudspeakers

Specifications
Specifications
Description

The design of the Quint Audio S18 provides high efficiency output associated with a deep bass foundation. Musicians, jazz-, classical- and contemporary-music engineers appreciate the S18 even more for its linearity and utmost musical behavior and high output.

The S18 is easily stackable and due to its compact size, it is a very useful building block for bass arrays and/or cardioid bass setups.

This makes this 1×18″ND sub deployable in all common PA- applications such as live theater, live events, pop concerts, jazz events, clubs, dance events etcetera.


Application area

Concert Sub
PA Sub
Cardioid Setup
EndFire Setup

Live Music
Mechanical Music


Specifications
S18
18" bassreflex sub
none
1600W
3200W
8 Ohms
97 dB 1W/1m
132 dB 1m
138dB 1m
37 - 400Hz
omni
41 kg
580 x 580 x 680 mm

Advised electronics

P4 processor
A1 amplifier
A23 amplifier
A41 amplifier
A42 amplifier


Downloads

Rigging
